TDP2 Parallel Release Mechanism

The TDP2 Parallel Release Mechanism is manufactured from high-strength steel, galvanized and painted, providing excellent corrosion resistance, making it ideal for long-term deployment.

Message

Product details

Product introduction

The TDP2 Parallel Release Mechanism is manufactured from high-strength steel, galvanized and painted, providing excellent corrosion resistance, making it ideal for long-term deployment. It can withstand at least three years of continuous operation in seawater without corrosion. This mechanism can be easily assembled on-site and, in most cases, installed without any modifications to the Sino-ART acoustic release itself. The standard maximum load for the TDP2 is 5,500 kg. Additionally, custom frames for specific applications or higher load ratings can be provided upon special request.

Main application scenarios

Strong, reliable, durable, corrosion-resistant;
Low power consumption, suitable for long-term mooring;
Full ocean depth, operable in low-temperature environments;
Low maintenance or maintenance-free;
Dual acoustic release mechanism significantly increases recovery rate;
Parallel release mechanism can provide additional working load capacity

Technical specification

(1) Operating Depth: 6000m;

(2) Length: 1023mm (excluding chain);

(3) Width: 510mm;

(4) Maximum Load: 5500 kg;

(5) Material: 316 Stainless Steel (Titanium alloy optional);

(6) Corrosion Resistance: Supports continuous operation in seawater for 3 years (corrosion-free);

(7) Weight in Air: 27.7 kg;

(8) Weight in Water: 19 kg;
