Serial Number

Parameter

Performance

1

Amplification Factor

10 times

2

Output Impedance

100 Ω

3

Bandpass Filter

0.1Hz - 120Khz

4

Maximum Output Voltage

10Vpp (The peak-to-peak value of the output voltage is at most 10V)

5

Dynamic Range

≥60dB (The range from the minimum to the maximum signal that the device can handle is 60 decibels or more)

6

Enclosure Material

Aluminum alloy (6061)

7

Output Type

Differential Output (The output signal adopts the form of differential signal, that is, the signal is transmitted through the voltage difference between two signal lines)

8

Driving Cable Length

100m (The device can normally drive a cable with a length of 100 meters for signal transmission)

9

Operating Voltage

5 - 20V, Power ≤ 25W (The voltage range required for the device to work properly is between 5 volts and 20 volts, and the power consumed during operation does not exceed 25 watts)

10

Dimensions

≤163*140*63mm (The maximum external dimensions (length × width × height) of the device do not exceed 163 mm × 140 mm × 63 mm)

11

Weight

≤500g (The maximum weight of the device does not exceed 500 grams)

12

Operating Temperature

-40 ～ +70°C (The device can work properly within the temperature range from -40 degrees Celsius to +70 degrees Celsius)

13

Storage Temperature

-40 ～ +70°C (The device can be safely stored within the temperature range from -40 degrees Celsius to +70 degrees Celsius)

14

Mean Time Between Failures (MTBF)

≥50000h (The average time interval between two failures of the device is not less than 50000 hours)

15

Others

① The input, output, including the power interface, have shielding functions (The input interface, output interface, and power interface of the device are all equipped with shielding measures to reduce the impact of external electromagnetic interference on the device).② The amplifier starts automatically when powered on (When the amplifier is powered on, it will start working automatically without additional manual operation).
